VW VOLKSWAGEN Car Radio Stereo Audio Wiring Diagram Autoradio connector wire installation schematic schema esquema de conexiones stecker konektor connecteur cable shema car stereo harness wire speaker pinout connectors power how to install













VW SHARAN, FORD GALAXY, SEAT ALHAMBRA

VW Sharan, Ford Galaxy, Seat Alhambra

1-+12 VOLT IGNITION WIRE

9-SPEAKER RR+

14-SPEAKER LF-

2-GND

10-SPEAKER RR-

15-SPEAKER LR+

3-+12 VOLT BATTERY WIRE

11-SPEAKER RF+

16-SPEAKER LR-

4-DASH LIGHT DIMMER WIRE

12-SPEAKER RF-

-

5-Power Antenna Turn On

13-SPEAKER LF+

-



VW BETA V

VW BETA V

A

C

1-GALA

7-TEL+

2-TEL MUTE

11-REM-C

3-V.BUS

12-TEL-

4-+12 VOLT BATTERY WIRE

13-DATA IN

5-+12V

14-DATA OUT

6-Dash Light Dimmer Wire

15-CLOCK

7-+12 VOLT IGNITION WIRE

16-UB+

8-GND

-

B

18-COM (GND)

3-Speaker RF+

19-AF-L

4-Speaker RF-

20-AF-R

5-Speaker LF+

-

6-Speaker LF-

-



VW CQ-JV1060L



VW Radio Navigation System MCD  Blaupunkt



VW Navigation System
The main power connector, CD ,
speakers



Connector navigation system



Blaupunkt

VW Gamma Dotmatrix
7 649 207 360
7 649 207 460 (China Kit)
VW Gamma Dotmatrix Release
7 649 208 360
VW Gamma ohne/without RP 6:00
7 641 207 360
VW Gamma mit/with RP 6:00
7 641 208 360
VW Gamma Release (Nokia)
7 648 231 060/360
VW Gamma (Nokia)
7 648 232 060/360
7 648 232 460 (China Kit)
VW Gamma T4 Release
7 648 237 060/360
VW Gamma T4
7 648 239 060/360

VW Gamma Release
7 648 225 060/360
VW Gamma
7 648 227 060/360
VW New Beetle
7 648 229 060/360








Blaupunkt alpha CC Europa



Grundig auto radio Alpha 4, Beta3, Beta4, Beta5, Sound 5000




Car radio      Model autoradio Manufacturer MCU EEPROM IC Amplifier CD changer  Car
VW ALPHA BLAUPUNKT   TDA2003
VW ALPHA BLAUPUNKT TMS1000NSC NEMA
VW ALPHA CC POLO VWZ1Z1 BLAUPUNKT TMP47C847F-G498 4C016 smd TDA7376B
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C446AFP831 4C016 smd TDA2005
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C446AF-UK04  (8924901578) 4C016 smd
VW ALPHA CC VWZ1Z1 BLAUPUNKT 47C847F-G498 4C016 smd
VW ALPHA IV  VWZ2Z1 BLAUPUNKT   TDA2005
VW ALPHA IV  VWZ2Z1 GRUNDIG D17011GF E91 24C02
VW ALPHA IV  VWZ6Z1     DC587 PHILIPS P83CE654FFB 24C08 TDA7375
VW ALPHA IV  VWZ6Z1     DC587 VA PHILIPS P83CE588EFB 004  RC5-DC587VA 24C02 smd TDA1518BQ
VW ALPHA IV  VWZ6Z1     DC587/71 PHILIPS S87C654-5B44         RC1-DC587 24C02 smd     LUPO, POLO, GOLF,T5
VW ALPHA V  BLAUPUNKT S4B5A115PJ F11-33A4JGW (8925905216) 95160 smd     LUPO, POLO, GOLF,T5
VW ALPHA V VWZ1Z1 BLAUPUNKT 95160 smd
VW ALPHA VWZ1Z1   4C14 smd        24C01
VW ALPHA VWZ2Z1 GRUNDIG D17011GF E91( E93 or E94 )
VW     BETA  VWZ1Z2 BLAUPUNKT HC84AH2LW (8925904314) 25C160
VW BETA  VWZ1Z2 BLAUPUNKT HI 020353W (8924904615) 25C160
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT H11-19A3C9W  S4B5A092PJ  (8925904615) 25C160
VW BETA  VWZ1Z2 BLAUPUNKT HC85AOX4W 25C160
VW BETA  VWZ1Z2 BLAUPUNKT HC84AFY6W  (8925904314) 25LC160
VW BETA  VWZ1Z2 BLAUPUNKT HC85A460W  (8925904314) 25C160
VW BETA  VWZ1Z2 BLAUPUNKT       LUPO
VW BETA  VWZ1Z2 BLAUPUNKT       LUPO
VW BETA  VWZ1Z2 BLAUPUNKT       VAN T4
VW BETA  VWZ1Z2 BLAUPUNKT       VAN T4
VW  BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT 25C160
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT 95C160
VW  BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT H11-06AK72W  (8925904615) 25160     VAN T4
VW BETA  VWZ1Z2 BLAUPUNKT       VAN T4
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT   TDA7376
VW BETA  VWZ1Z2 BLAUPUNKT H11-91A3XTW  (8925904430) 25160
VW BETA  VWZ1Z2 BLAUPUNKT   TDA7376B
VW  BETA  VWZ1Z2 BLAUPUNKT H11-93AK8K8W 25C160 smd
VW BETA  VWZ1Z2 BLAUPUNKT 25C160   CDC-A08 , IDC-A09 POLO , LUPO
VW BETA  VWZ1Z2 BLAUPUNKT ST7282       POLO , LUPO
VW BETA  VWZ1Z2 BLAUPUNKT 25C160     VAN T4
VW BETA  VWZ1Z2 BLAUPUNKT       VAN T4
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT
VW BETA  VWZ1Z2 BLAUPUNKT HC83AC5DWXC4B5A060 25C160
VW BETA  VWZ1Z2 BLAUPUNKT H11-19A3C9W   S4B5A092PJ  (8924904615) 25C160
VW BETA  VWZ1Z2 BLAUPUNKT HC83AC5DWX  S4B5A060 25C160
VW BETA  VWZ9Z2  PE-HP01W-01 CLARION LC72358 93LC46 smd
VW BETA 3 VWZ2Z2 GRUNDIG D7508HC188 TDA1556Q
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA 4)            NO SEC MCU TDA1556Q
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA 4)            NO SEC MCU TDA1556Q
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA 4)            NO SEC MCU TDA7375A
VW BETA 5 VWZ2Z2 GRUNDIG MC68HC11KA2CFN2  ( VW BETA 5 ) MCU
VW BETA 5 VWZ2Z2 GRUNDIG MC68HC11KA2CFN2  ( VW BETA 5 ) MCU
VW BETA B BLAUPUNKT
VW BETA CC VWZ1Z2 BLAUPUNKT MC68HC05B8  (8925900979)
VW BETA CC VWZ1Z2 BLAUPUNKT ZC400882CFN  MC68HC05B8  (8925900978) MCU
VW BETA CC VWZ1Z2 BLAUPUNKT 47C446AF 1927 93C46
VW BETA MATRIX VWZ1Z2  BLAUPUNKT                          (8925904615) 25C160
VW BETA T4 VWZ1Z2 BLAUPUNKT   TDA7576B
VW BETA T4 VWZ1Z2 BLAUPUNKT H11-14ACLJW  (8925904615) 95C160 smd
VW BETA T4 VWZ1Z2 BLAUPUNKT 25C160
VW BETA V VWZ1Z2 BLAUPUNKT H11-OAA9R8W  (8925904615)  S4B5AO92PJ 25C160
VW BETA V VWZ1Z2 BLAUPUNKT -8,926E+09 25C160
VW BETA V VWZ1Z2 BLAUPUNKT HC-84AH2DW  (8925904314) 25LC160
VW BETA V VWZ6Z2  DC589/71B PHILIPS P83CE560EFB 001 or  032  RC1 VB5 24C16 smd
VW BETA V VWZ6Z2  DC589/71B PHILIPS P83CE560EFB048  05105611  RC5 VB5 24C16 smd     PASSAT 2002
VW DC668 PHILIPS D1713AG614 INTEL 5C032 (PLD)   PASSAT 2002
VW DELTA 6 VWZ4Z4  2DIN NAVIGATION DELPHI D70F3044YGC ST24C16     PASSAT B6 2004
VW DELUXE AUDIO ( PE-9840W01 ) CLARION D17003AGF 653 93C46
VW DELUXE AUDIO ( PO-9840-01 ) VWZ9Z6 CLARION D17005GF 724 93C46 4xTDA2003
VW GAMMA 2 VWZ2Z3 GRUNDIG HYBRID PLASTIC NMC9306
VW GAMMA 2A VWZ2Z3 GRUNDIG HYBRID PLASTIC NMC9306 2xTDA1516Q
VW GAMMA 3 VWZ6Z3 PHILIPS TMP47P860N 2404+2402 2xTDA1516Q
VW GAMMA 3 VWZ6Z3 PHILIPS TMP47P860N 2404+2404
VW GAMMA BNO BLAUPUNKT H11-9CA-…(8925904476) 25C160
VW GAMMA C BLAUPUNKT
VW GAMMA CC MATSUSHITA
VW GAMMA CC BLAUPUNKT TI   (8925904614) 25C160
VW GAMMA CD MATSUSHITA      D75112GF 580 93C06
VW GAMMA CD MATSUSHITA S2444
VW GAMMA D BLAUPUNKT HC83AFVCWXS4B5A062 (8925904315) 25LC160 2xTDA2005
VW GAMMA II (M327) VWZ1Z3 BLAUPUNKT HYBRID CERAMIC  033 MCU
VW GAMMA II (M330) BLAUPUNKT HYBRID CERAMIC
VW GAMMA IIa BLAUPUNKT
VW GAMMA III BLAUPUNKT
VW GAMMA IV MATSUSHITA YEAMH8338F03 93C06
VW GAMMA IV VWZ5Z3 MATSUSHITA YEAMH8338F01 93C06 2xTDA7374
VW GAMMA IV VWZ6Z3   22DC588/71 PHILIPS P83CE558EFB 002  or 004  or  020  RC3-DC588 24C16
VW GAMMA IV VWZ6Z3   22DC588/71E PHILIPS P83CE558EFB 020 24C16     VAN T4
VW GAMMA T4 BLAUPUNKT       VAN T4
VW GAMMA T4 BLAUPUNKT       VAN T4
VW GAMMA T4 BLAUPUNKT       VAN T4
VW GAMMA T4 BLAUPUNKT H11-05AD7HW (8925904614) 25LC160
VW GAMMA V CLARION LC72P366 93LC46 smd
VW GAMMA V  VWZ3Z3 SONY MN1886426 + D78078GF087 2404 smd
VW GAMMA VWZ1Z3 BLAUPUNKT HC83A9EKW  XS485A062 (8925904315) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC89A7YTW 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT
VW GAMMA VWZ1Z3 BLAUPUNKT
VW GAMMA VWZ1Z3 BLAUPUNKT H11-OCAN65W  XS4B5A091PJ  (8925904614) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC86AC2HW 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC84AH2DW   (8925904315) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT H11-05AD7FW (8925904614) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT   2xTDA7376B
VW GAMMA VWZ1Z3 BLAUPUNKT TMC370C16B5A NM25C160  ,  M92256
VW GAMMA VWZ1Z3 BLAUPUNKT
VW GAMMA VWZ1Z3 BLAUPUNKT       POLO
VW GAMMA VWZ1Z3 BLAUPUNKT       POLO
VW GAMMA VWZ1Z3 BLAUPUNKT       POLO
VW GAMMA VWZ1Z3 BLAUPUNKT       POLO
VW GAMMA VWZ1Z3 BLAUPUNKT
VW GAMMA VWZ1Z3 BLAUPUNKT HC8AA20KW  XS4B5A062 (8925904315) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC83AH68W 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC83AFXOW 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC83AH61W (8925904315) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT TMS370C16B5A 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC83AFXOW  XS4B5A062 (8925904315) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT
VW GAMMA VWZ1Z3 BLAUPUNKT HC8AA2H6W  XS4B5A062 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC8AA117W  XS4B5A062 (8925904315) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC89A82 30321 (8925904315) 25LC160
VW GAMMA VWZ1Z3 BLAUPUNKT HC89A82 30321 (8925904315) 25LC160   CDC-A08 , IDC-A09
VW GAMMA VWZ1Z3 BLAUPUNKT
VW GAMMA VWZ4Z3  HITACHI   S2444 2xTA7280P
VW GAMMA VWZ4Z3  HITACHI D75104G-593 + D17P19G X24C44
VW NAVIGATION TRENDLINE BLAUPUNKT
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT -8,926E+09 25LC160 2xTDA7376B   NEW  BEETLE
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT HC8AA20KW (8925904315) 25LC160   CDC-A08 , IDC-A09 NEW  BEETLE
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT       NEW  BEETLE
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT       NEW  BEETLE
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT       NEW  BEETLE
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT HC8AA20KW (8925904315) 25LC160     NEW  BEETLE
VW NEW BEETLE  VWZ4Z7 DELCO   9355092
VW PREMIUM AUDIO MATSUSHITA D17010GF533 AM162286
VW PREMIUM AUDIO II  MATSUSHITA D17010GF533 9306
VW PREMIUM AUDIO III MATSUSHITA D17010GF581 93C46
VW PREMIUM AUDIO III CLARION
VW PREMIUM AUDIO PE-9838W  CLARION
VW PREMIUM AUDIO PE-9839W01 VWZ9Z7 CLARION D75517GF 732 93C46
VW PREMIUM AUDIO PO-9840 CLARION D17005GF724 93C46     NEW BEETLE
VW PREMIUM IV  ( PU-1569A )  VWZ9Z7 CLARION MB89F677AR 93C46 smd
VW PREMIUM IV  ( PU-1582A )  VWZ9Z7 CLARION MB89F677AR 93C46 smd
VW PREMIUM IV  ( PU-1634A )  VWZ9Z7 CLARION MB89F677-169 93C66
VW PREMIUM IV  ( PU-1666A ) CLARION MB89F677AR 93C46
VW PREMIUM V VWZ4Z7 DELCO N60 (09370082) 24C04
VW PU-1667A CLARION
VW RADIO NAVIGATION SYSTEM DELCO
VW RADIO NAVIGATION SYSTEM BLAUPUNKT FIS (8638340560A02) 2xTDA7376B
VW RADIO NAVIGATION SYSTEM BLAUPUNKT FIS
VW RADIO NAVIGATION SYSTEM BLAUPUNKT FIS
VW RADIO NAVIGATION SYSTEM   VWZ1Z2 BLAUPUNKT FIS modul
VW RADIO NAVIGATION SYSTEM   VWZ1Z2  MCD BLAUPUNKT FIS modul
VW RADIO NAVIGATION SYSTEM   VWZ1Z2  MCD BLAUPUNKT FIS 25C160
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS modul
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS moduł         TOUAREG
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS modul   2xTDA7376B   TOUAREG
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS moduł  (8638348807)
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS moduł  (8638348807)
VW RADIO NAVIGATION SYSTEM   VWZ1Z7  MFD     BLAUPUNKT FIS modul  (8618842980)
VW RADIO NAVIGATION SYSTEM   VWZ1ZZ BLAUPUNKT
VW RADIO NAVIGATION SYSTEM  MCD VWZ1Z2 BLAUPUNKT FIS 25C160 smd     TOURAN
VW RADIO NAVIGATION SYSTEM  MCD VWZ1Z2 BLAUPUNKT FIS (8638340560A02 or 472A03) 25C160 smd     TOURAN
VW RADIO NAVIGATION SYSTEM 2  T5 BLAUPUNKT FIS (8638340559) M95320 smd + M25P10 smd TDA7454
VW RADIO NAVIGATION SYSTEM 2  A-MPV BLAUPUNKT FIS (8638340559) M95320 smd + M25P10 smd TDA7454
VW RCD300 BLAUPUNKT D70F3079 (8611200639) M95320 smd + M25P10 smd TDA7564
VW RCD300  VWZ1Z2 BLAUPUNKT 95040 TDA7564
VW RCD500 BLAUPUNKT D703088 (8925905273) M95640 smd TDA7564
VW SC88A CLARION D1719G 611
VW SC88B CLARION
VW SOUND 2000 GRUNDIG
VW SOUND 3000 GRUNDIG D17006AGFE47 GRN007
VW SOUND 4000 GRUNDIG MC68HC11KA4  WKC5LMC-05 MCU
VW SOUND1 RDS VWZ7Z2 ( FORD 2006 ) FORD TMS370C758A  (N760050BFKC108)  R25831FNA MCU
VW SOUND1 RDS VWZ7Z2 ( FORD 2006 ) FORD TMS370C758A  (N760050BFKC105)  R25819FNA 2xTDA7360
VW SOUND1 RDS VWZ7Z2 ( FORD 2006R ) FORD TMS370C758A  (N760050BFKC105) MCU
VW SOUND1 RDS VWZ7Z2 ( FORD 2006R ) FORD TMS370C758A  (N760050BFKC107)
VW SOUND2 RDS VWZ7Z3 ( FORD 2007 ) FORD TMS370C758A  (N760050BFKC105)
VW SOUND2 RDS VWZ7Z3 ( FORD 2007 ) FORD TMS370C758A  (N760050BFKC107) NEMA
VW SOUND2 RDS VWZ7Z3  FORD TMS370C758A  (N760050BFKC103) MCU NEMA

( FORD 2007R RDS CD control )
VW SOUND2 RDS VWZ7Z3  FORD TMS370C758A  (N760050BFKC103) MCU

( FORD 2007R RDS CD control )
VW 6315OE EUROVOX D1708AG338
VW ALPHA only tuner BLAUPUNKT TMS1000NSC TDA2003
VW ALPHA only tuner GRUNDIG D1719G 643 TA8208H
VW ALPHA IV VWZ6Z1     DC587 PHILIPS P83CE654FFB 24C08
VW ALPHA IV VWZ6Z1 PHILIPS S87C654-5B44 24C02 smd TDA1518BQ
VW ALPHA IV VWZ6Z1     DC587 PHILIPS RC2 DC587 24C02 smd TDA1518BQ
VW ALPHA IV VWZ6Z1     DC587/71 PHILIPS RC4 DC587 24C02 smd TDA1518BQ
VW ALPHA IV VWZ6Z1     DC587 VA PHILIPS RC5 DC587VA 24C02 smd TDA7375
VW ALPHA IV VWZ6Z1     DC587/71 PHILIPS RC1 DC587 24C02 smd TDA1518BQ
VW ALPHA IV VWZ6Z1     DC587/71E PHILIPS RC4 DC587 24C08 smd
VW ALPHA IV VWZ6Z1     DC587/71T PHILIPS RC4 DC587VA or P83CE654EFB  RC5DC587VA 24C08 smd TDA7375
VW ALPHA IV VWZ2Z1 GRUNDIG D17011GF E91 TDA2005
VW ALPHA 5  VWZ1Z1 BLAUPUNKT TMS370C16B5A (F11-2AA59JW   8925905216) 95160 smd + M35T02 smd TDA7376B
VW ALPHA 5  VWZ1Z1 BLAUPUNKT TMS370C16B5A (F11-2AA59JW   8925905216) 95160 smd TDA7376B
VW ALPHA 5  VWZ1Z1 BLAUPUNKT TMS370C16B5A (F11-2CAH76W   8925905216) 95160 smd + M35T02 smd TDA7376B
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C446AFP831 (8925901578) 4C016 smd TDA7376B
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C446AF-UK04 (8925901578) 4C016 smd TDA2005
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C446AF-UK04 (8925901578) 4C016 smd TDA7376B
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C446AF-UK04 (8925901578) 4C016 smd TDA7376B
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C847F-G498 4C016 smd
VW ALPHA CC EU  VWZ1Z1 BLAUPUNKT TMP47C847F-G498 (8925904133) 24C01 smd TDA7376B
VW ALPHA CC EU  VWZ1Z1 BLAUPUNKT TMP47C847F-G498 (8925904133) 24C01 smd TDA7376B
VW ALPHA CC EU  VWZ1Z1 BLAUPUNKT TMP47C847F-G498 (8925904133) 24C01 smd TDA7376B
VW ALPHA CC VWZ1Z1 BLAUPUNKT TMP47C847F-G498 4C016 smd TDA7376B
VW ALPHA CC POLO VWZ1Z1 BLAUPUNKT TMP47C446AF-UK04 (8925901578) 4C016 smd TDA2005
VW AUTOBAHN   TMP47C420AF8357 X2444 mPC1318C x 2
VW AUTOBAHN     X2444
VW BETA VWZ1Z2 BLAUPUNKT TMS370C16B5A (F11-46AD7DW, 8925904615) 25160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT HC-84AH2LW (8925904314) 25LC160 smd + M92256 smd
VW BETA VWZ1Z2 BLAUPUNKT TMS370C16B5A (H11-07AD93W, 8925904615) 25LC160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT HC-84AH29W (8925904314) 25LC160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT HC-83AC5KW (8925901863) 25LC160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT 25LC160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT HC-84AFY6W (8925904314) 25LC160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT H11-91A3XTW (8925904430) 25160 TDA7376
VW BETA VWZ1Z2 BLAUPUNKT TMS370C16B5A (F11-23A7H7W, 8925904615) 95160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT TMS370C16B5A (H11-11ADL2W, 8925904615) 95160 smd + M92256 smd TDA7376B
VW BETA VWZ1Z2 BLAUPUNKT TMS370C16B5A (H11-08AJ2DW, 8925904615) 25160 smd + M92256 smd TDA7376B
VW BETA VWZ9Z2   PE-HP01W-01 CLARION LC72358 93LC46 smd
VW BETA II VWZ6Z2 PHILIPS 47C421AF8522 (BETA3) TDA1515A
VW BETA 2 VWZ2Z2 GRUNDIG D7507G646 BETA02 TDA2003 x 2
VW BETA 3 VWZ2Z2 GRUNDIG D7508HC188 TDA1553Q
VW BETA III VWZ3Z2 80C51
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA4) TDA1556Q
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA4) TDA1556Q
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA4) TDA1556Q
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA4) TDA1556Q
VW BETA 4 VWZ2Z2 GRUNDIG MC68HC11E9  (VW BETA4) TDA1556Q
VW BETA CC (M158) VWZ1Z2 BLAUPUNKT TMP47C446AF1927 93C46 TDA2005 x 2
VW BETA CC VWZ1Z2 BLAUPUNKT MC68HC05B8 (8925900979 or ZC400882CFN 8925900978) TDA1556Q
VW BETA 5 VWZ2Z2 GRUNDIG MC68HC11KA4 or 711KA2 (VW BETA 5) TDA7375A
VW BETA 5 VWZ2Z2 GRUNDIG MC68HC11KA4 (VW BETA 5 DOT or VW BETA 5(99)) TDA7375A
VW BETA V VWZ6Z2  DC589/71B PHILIPS P87CE560EFB01 or P83CE560EFB032  RC1 VB5 24C16 smd TDA7375A
VW BETA V VWZ6Z2  DC589/71B PHILIPS P87CE560EFB01 or P83CE560EFB048  05105611  RC5 VB5 24C16 smd TDA7375A
VW BETA V VWZ1Z2 BLAUPUNKT HC83AC5DWXC4B5A060 25C160 smd TDA7376B
VW BETA T4  VWZ1Z2 BLAUPUNKT F11-14ACLJW (8 925 904 615) 95160 smd TDA7376B
VW CD PLAYER AUDIO SYSTEM   VWZ4Z3 SAMSUNG
VW COLORADO RADIO US   VWZ4Z7 DELCO D70F3044YGC 24C16 smd
VW COLORADO RADIO US   VWZ4Z7 DELCO D70F3044YGC 24C16 smd
VW DC668 PHILIPS D1713AG614 INTEL 5C032 (PLD)
VW DELTA II (M328) VWZ1Z4 BLAUPUNKT HYBRID CERAMIC (8638309031) TDA2005 x 2
VW DELTA  VWZ4Z4 DELCO D70F3044YGC 24C16 smd TDA7454
VW DELTA  VWZ4Z4 DELCO
VW DELTA6 VWZ4Z4 DELCO D70F3044YGC 24C16 smd TDA7454
VW DELTA6 VWZ4Z4 DELCO D70F3044YGC 24C16 smd TDA7454
VW DELTA6 VWZ4Z4 DELCO D70F3044YGC 24C16 smd TDA7454
VW DELUXE AUDIO  VWZ5Z6 MATSUSHITA D17005GF623 AM162286 or 93C06 TA8210AH
VW DELUXE AUDIO  VWZ9Z6 PO-9840W01 CLARION D17005GF724 93C46 TA8210AH
VW DELUXE AUDIO  PE-9840W01 CLARION D17003AGF653 93C46
VW DESIGN SC88A CLARION D1719G611
VW DX-5V101R  VWZ3Z4 SONY   24C01
VW GAMMA VWZ1Z3 BLAUPUNKT XS4B5A062 (8925904315) 25LC160 smd + M92256 smd TDA7376B x 2
VW GAMMA VWZ1Z3 BLAUPUNKT H11-92AEE3W (8925904476) 25LC160 smd + M92256 smd TDA7376B x 2
VW GAMMA VWZ1Z3 BLAUPUNKT H11-05AF9RW (8925904614) 25LC160 smd + M92256 smd TDA7376B x 2
VW GAMMA VWZ1Z3 BLAUPUNKT XS4B5A062 (8925904315) 25LC160 smd + M92256 smd
VW GAMMA VWZ1Z3 BLAUPUNKT H11-06AFVCW (8925904614 or 315) 95160 smd + M92256 smd TDA7376B x 2
VW GAMMA VWZ1Z3 BLAUPUNKT 95160 smd + M92256 smd
VW GAMMA VWZ1Z3 BLAUPUNKT H11-05AD7HW (8925904614 or 904476) 25LC160 smd + M92256 smd TDA7376B x 2
VW GAMMA VWZ1Z3 BLAUPUNKT F11-13A5LLW  (8925904614) 95160 smd + M92256 smd TDA7376B x 2
VW GAMMA M327  VWZ4Z3 HITACHI D1714G633 S2444
VW GAMMA M327  VWZ4Z3 HITACHI D75104G593 + D17P19G X24C44 TA7280P x 2
VW GAMMA 2 VWZ2Z3 GRUNDIG HYBRID PLASTIC NMC9306 TDA2003 x 4
VW GAMMA 2A VWZ2Z3 GRUNDIG HYBRID PLASTIC NMC9306 TDA2003 x 4
VW GAMMA 3 VWZ6Z3 PHILIPS TMP47P860N 2404+2404 TDA1516Q x 2
VW GAMMA 3 VWZ6Z3 PHILIPS TMP47P860N 2404+2402 TDA1516Q x 2
VW GAMMA 3 VWZ6Z3    DC586/71 PHILIPS TMP47P860N 2404+2404 TDA1516Q x 2
VW GAMMA II (M327) VWZ1Z3 BLAUPUNKT HYBRID CERAMIC (8638309033) TDA2005 x 2
VW GAMMA II A (M972) VWZ1Z3 BLAUPUNKT HYBRID CERAMIC (8638309259A) TDA2005 x 2
VW GAMMA IV VWZ6Z3   DC588/71 PHILIPS P83CE558EFB002 or 020 24C16 TDA7374 x 2
VW GAMMA IV VWZ6Z3   DC588/71E PHILIPS P83CE558EFB106 or 020  (RC3-DC588/71) 24C16 TDA7375 x 2
VW GAMMA IV VWZ5Z3 MATSUSHITA YEAMH8338F01 or YEAMH8338F03 6433388F10 A35 93C06 TA8220H x 2
VW GAMMA IV VWZ5Z3 MATSUSHITA YEAMH8338F04  6433388F10 A55 93C06 TA8220H x 2
VW GAMMA IV VWZ5Z3 MATSUSHITA YEAMH8338F03  6433388F10 A35 93C06 TA8220H x 2
VW GAMMA V VWZ3Z3 SONY MN1886426 + D78078GF087 2404 smd TDA8563AQ x 2
VW GAMMA V VWZ9Z3 PE-HP05W-01 CLARION LC72P366 93LC46 smd
VW GAMMA V VWZAZ3D2 TECHNISAT M38869FFAHP 24C08 smd x 2 TDA7454
VW GAMMA CC MATSUSHITA
VW GAMMA CD MATSUSHITA
VW GAMMA CD  VWZ5Z5 MATSUSHITA D78214GC522 ST61907 NO
VW GAMMA T4  VWZ1Z3 BLAUPUNKT H11-05AD7HW (8925904614 or 904476) 25LC160 smd TDA7376B x 2
VW H0004/S0003   VWZ4Z5 DELCO D70F3044YGC 9375365 smd
VW H0006/S0009   VWZ4Z7 DELCO D70F3044YGC 9375365 smd
VW MID EU   VWZ1Z3 BLAUPUNKT D70F3356GJ M95128 smd TDA7564B
VW MID EU DAB   VWZ1Z3 BLAUPUNKT M95128 smd
VW MID RVC   VWZ1Z3 BLAUPUNKT M95128 smd
VW MINIDISC MDX-5V101P  VWZ3Z4B SONY D784216GC051 24C01 TDA8563AQ x 2
VW NAVIGATION LOWLINE BLAUPUNKT D70F3079 + STA2052 M95320 smd + M25P10 smd TDA7564
VW NAVIGATION LOWLINE BLAUPUNKT D70F3079 + STA2052 M95320 smd + M25P10 smd TDA7564
VW NAVIGATION LOWLINE MP3 BLAUPUNKT D70F3079 + STA2052 M95320 smd + M25P10 smd TDA7564
VW NAVIGATION LOWLINE BLAUPUNKT D70F3079 + STA2052 M95320 smd + M25P10 smd TDA7564
VW NAVIGATION SYSTEM  VWX-8V51 VR  VWZ3Z1 SONY
VW NEW BEETLE ALPHA  only tuner BLAUPUNKT AT25160 smd TDA7376B x 2
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT HC8AA20KW (8925904315) AT25160 smd TDA7376B x 2
VW NEW BEETLE  VWZ1Z3 BLAUPUNKT H11-05AD7HW (8925904614) AT25160 smd TDA7376B x 2
VW NEW BEETLE MONSOON  VWZ4Z7 DELCO N60 FLASH (09370082) 9355092 smd TDA7376B x 2
VW NEW BEETLE CD MONSOON  VWZ4Z7 DELCO   9375365 smd
VW NEW BEETLE JAPAN  VWZ1Z3 BLAUPUNKT H11-97D5E1W  (8925904940) AT25160 smd TDA7376B x 2
VW NEW BEETLE CD RADIO EUR  H0002/S0003 VWZ4Z5 DELCO D70F3044YGC 9375365 smd
VW PHAETON VWZ6Z9 VDO
VW PREMIUM AUDIO MATSUSHITA D17010GF533 AM162286
VW PREMIUM AUDIO PE-9838W CLARION
VW PREMIUM AUDIO PE-9839W01 VWZ9Z7 CLARION D75517GF372 93C46 TDA1555Q x 2
VW PREMIUM AUDIO II  VWZ5Z7 MATSUSHITA D17010GF533 93C06 TA8220 x 2
VW PREMIUM AUDIO II MATSUSHITA D17010GF533 93C06
VW PREMIUM AUDIO III  VWZ5Z7 MATSUSHITA D17010GF581 93C06 smd
VW PREMIUM IV  PU-1569A  VWZ9Z7 CLARION MB89677AR 93C46 smd
VW PREMIUM IV  PU-1582A-C  VWZ9Z7 CLARION MB89677AR159 or AR164 93C46 smd TDA7396 x 4
VW PREMIUM IV  PU-1634A  VWZ9Z7 CLARION MB89677AR168 or AR169 93C46 smd TDA7396 x 4
VW PREMIUM IV  PU-1635A  VWZ9Z7 CLARION MB89677AR 93C46 smd TDA7396 x 4
VW PREMIUM IV  PU-1666A  VWZ9Z7 CLARION MB89677AR175 or AR190 93C46 smd TDA7396 x 4
VW PREMIUM IV NB  PU-1667A  VWZ9Z7 CLARION MB89677AR168 or AR190 93C46 smd TDA7396 x 4
VW PREMIUM 5 VWZ4Z7 DELCO N60 FLASH (09370082) 9355092 smd TDA7376B x 2
VW PREMIUM 5 VWZ4Z7 DELCO N60 FLASH (09370082) 24C04 smd TDA7376B x 2
VW PREMIUM 6 MATSUSHITA SAFC161CI32F16F (C2CBKA00001) S220 TDA7454
VW PREMIUM 6 MONSOON  VWZ5Z7 MATSUSHITA SAFC161CI32F16F S220 TDA7454
VW PREMIUM 6 MONSOON  VWZ5Z7 MATSUSHITA SAFC161CS32RF (C2CBKH000028) S220 TDA7454
VW PREMIUM 6 MONSOON  VWZ5Z7 MATSUSHITA
VW PREMIUM 6 VWZ5Z7 MATSUSHITA S220
VW PREMIUM 6 VWZ5Z7 MATSUSHITA SAFC161CS32RF (C2CBKH000060) S220 TDA7454
VW PREMIUM 6 VWZ5Z7 MATSUSHITA SAFC161CS32RF (C2CBKH000060) S220
VW PREMIUM 6 VWZ5Z7 MATSUSHITA SAFC161CS32RF (C2CBKH000063) S220 TDA7454
VW PREMIUM 6 VWZ5Z7 MATSUSHITA S220
VW PREMIUM 6 MONSOON  VWZ5Z7 MATSUSHITA SAFC161CS32RF (C2CBKH000077) S220 TDA7454
VW PREMIUM 6 MONSOON  VWZ5Z7 MATSUSHITA SAFC161CS32RF (C2CBKH000077) S220 TDA7454
VW PREMIUM VI MONSOON  PU-2354A  VWZ9Z7 CLARION MB90F594A  K33 or K82 93LC66 smd TDA7454
VW PREMIUM VI MONSOON  PU-2354A  VWZ9Z7 CLARION MB90F594A  K37 93LC66 smd TDA7454
VW PREMIUM 7 MP3  VWZ4Z7 DELPHI
VW PREMIUM 7 6CD MP3  VWZ4Z7 DELPHI D70F3268TGC 9375365
VW PREMIUM 7 6CD MP3  VWZ4Z7 DELPHI   1001376
VW PREMIUM 7 6CD MP3  VWZ5Z7 MATSUSHITA
VW PREMIUM 7 6CD MP3  VWZ5Z7 MATSUSHITA
VW PREMIUM 7 6CD MP3  VWZ5Z7 MATSUSHITA M30833FJQP431H1A0 S330
VW PREMIUM 7 6CD MP3  VWZ5Z7 MATSUSHITA M30833FJGP S330 TDA7564
VW RADIO NAVIGATION SYSTEM DELCO
VW RADIO NAVIGATION SYSTEM   VWZ1Z2 BLAUPUNKT FIS (8638340560A02)
VW RADIO NAVIGATION SYSTEM   VWZ1Z2 BLAUPUNKT FIS (8638247721)
VW RADIO NAVIGATION SYSTEM MCD VWZ1Z2 BLAUPUNKT FIS 25C160 smd
VW RADIO NAVIGATION SYSTEM MCD VWZ1Z2 BLAUPUNKT FIS (8638340560A02 or 472A03) 25C160 smd TDA7454
VW RADIO NAVIGATION SYSTEM MCD VWZ1Z7 BLAUPUNKT FIS (8638340472003) TDA7376B x 2
VW RADIO NAVIGATION SYSTEM BLAUPUNKT FIS
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS (8638348807A02) TDA7376B x 2
VW RADIO NAVIGATION SYSTEM MFD  VWZ1Z7 BLAUPUNKT FIS (8638340559A02)
VW RADIO NAVIGATION SYSTEM BLAUPUNKT FIS (8638340560A02) TDA7376B x 2
VW RADIO NAVIGATION SYSTEM   VWZ1Z7 BLAUPUNKT FIS (8638340560A02) TDA7376B x 2
VW RADIO NAVIGATION SYSTEM MFD  VWZ1Z7 BLAUPUNKT FIS (8638340559A02 or 378807A02) TDA7376B x 2
VW RADIO NAVIGATION SYSTEM MFD  VWZ1Z7 BLAUPUNKT FIS (8638340559D03) TDA7376B x 2
VW RADIO NAVIGATION SYSTEM MFD  VWZ1Z7 BLAUPUNKT FIS (8638340559A02) TDA7376B x 2
VW RADIO NAVIGATION SYSTEM 2  DVD VWZ1Z7 BLAUPUNKT FIS (8638247719) + D70F3089YGJ M95320 smd + M25P10 smd TDA7564
VW RADIO NAVIGATION SYSTEM 2 BLAUPUNKT FIS (8638340559) + D70F3079AYGC (8609503138) M95320 smd + M25P10 smd TDA7454
VW RADIO NAVIGATION SYSTEM 2  T5  VWZ1Z7 BLAUPUNKT FIS (8638340559D03) + D70F3079AYGC (8609503138) M95320 smd + M25P10 smd TDA7454
VW RADIO NAVIGATION SYSTEM 2  T5 BLAUPUNKT FIS (8638340559) + D703078A (8609503138) M95320 smd + M25P10 smd TDA7454
VW RADIO NAVIGATION SYSTEM 2  VWZ1Z7 BLAUPUNKT FIS (8638340559D03) + D70F3079AYGC M95320 smd + M25P10 smd TDA7454
VW RADIO NAVIGATION SYSTEM 2  VWZ1Z7 BLAUPUNKT FIS (8638340559D03) + D70F3079AYGC M95320 smd + M25P10 smd TDA7454
VW RADIO NAVIGATION SYSTEM MFD2 A-MPV BLAUPUNKT FIS (8638340559A02) M95320 smd + M25P10 smd TDA7454
VW RADIO NAVIGATION SYSTEM MFD2 DVD BLAUPUNKT FIS (8638247719) + D70F3089YGJ M95320 smd TDA7564
VW RADIO NAVIGATION SYSTEM 2 DVD RDW BLAUPUNKT FIS (8638247719) + D70F3089YGJ M95320 smd TDA7564
VW RADIO NAVIGATION SYSTEM T5 RSE DVD BLAUPUNKT FIS + D70F3089YGJ M95320 smd TDA7564
VW R 100 BASIC  only tuner BLAUPUNKT D70F3079 (8925905274) M95320 smd + M25P10 smd TDA7566
VW RCD 200   VWZ1Z5 BLAUPUNKT D70F3079AYGC M95320 smd + M25P10 smd TDA7566
VW RCD 200 MP3  VWZ1Z5 BLAUPUNKT D70F3079AYGC M95320 smd + M25P10 smd TDA7566
VW RCD 200 TUPI  VWZ1Z7 BLAUPUNKT D70F3079AYGC M95320 smd + M25P10 smd TDA7566
VW RCD 200   VWZ4Z4 DELCO D70F3268YGC (09399462) 09400465 smd
VW RCD 300   VWZ2Z2 GRUNDIG   24C32 smd
VW RCD 300   VWZ2Z2 GRUNDIG   24C32 smd
VW RCD 300   VWZ2Z2 GRUNDIG D70F3079AYGC 24C32 smd + 25C256 smd TDA7566
VW RCD 300   VWZ2Z2 GRUNDIG D70F3079AYGC 24C32 smd + 25C256 smd TDA7566
VW RCD 300   VWZ2Z2 GRUNDIG D70F3079AYGC 24C32 smd + 25C256 smd TDA7566
VW RCD 300   VWZ2Z2 GRUNDIG   24C32 smd
VW RCD 300   VWZ1Z2 BLAUPUNKT M95640 smd + M25P10 smd TDA7564
VW RCD 300   VWZ1Z2 BLAUPUNKT D70F3079AYGC 25C320 smd + M25P10 smd TDA7564
VW RCD 300   VWZ1Z2 BLAUPUNKT D703088Y (8928906203) M95640 smd TDA7566
VW RCD 300   VWZ1Z2  TOURAN BLAUPUNKT D70F3079 (8611200639) M95320 smd + M25P10 smd TDA7564
VW RCD 300   VWZ1Z2  TOURAN BLAUPUNKT D70F3079 (8611200639) M95320 smd + M25P10 smd TDA7564
VW RCD 300   VWZ7Z2 VISTEON MC9S12DP512CPV TDA7566
VW RCD 300 MP3   VWZ1Z2 BLAUPUNKT D70F3283 (8611200692) M95640 smd TDA7566
VW RCD 310 LOW EU   VWZ1Z2 BLAUPUNKT D70F3358GJ M95C128 smd TDA7564B
VW RCD 500 MP3 MATSUSHITA M30833FJ 93C76 smd
VW RCD 500 MP3 MATSUSHITA M30833FJ 93C76 smd
VW RCD 500   VWZ1Z3 BLAUPUNKT D703088 (8925905273) M95640 smd TDA7564
VW RCD 500 CHROME BLAUPUNKT D703088 (8925905273) M95640 smd TDA7564
VW RCD 510 MID EU BLAUPUNKT M95C128 smd
VW RCD 510 MID RVC BLAUPUNKT M95C128 smd
VW RCD 510 MID EU DAB BLAUPUNKT M95C128 smd
VW RHAPSODY  VWZAZ6 TECHNISAT M38869FFAHP 24C08 smd + 24C08 smd TDA7454
VW RNS-510  VWZ6Z7 SIEMENS VDO
VW RNS-510DVD  VWZ6Z7 SIEMENS VDO TMS470 + ST10F276-CEG 24C64 smd + 24LC128 smd
VW SOUND1 RDS VWZ7Z2 ( FORD 2006 ) FORD TMS370C758A (N760050BFKC105 or BFKC107or BFKC108) TDA7360 x 2
VW SOUND1 RDS VWZ7Z2 ( FORD 2006 ) FORD TMS370C758A TDA7360 x 2
VW
